What effects does temperature have on linear guides?

Date: 2025.08.29 Views: 65

Linear guides are mechanical transmission components widely employed in industrial applications, playing a vital role in precision machinery and automated systems. Temperature constitutes a critical factor influencing the operational performance of linear guides. Below is a brief overview of the effects temperature exerts upon linear guides.

Linear expansion: Elevated temperatures cause the material of linear guides to expand linearly, altering the guide's dimensions. This induces geometric deviations in the guide, diminishing its operational precision and stability.

Friction characteristics: Rising temperatures cause the lubricant within linear guides to thin, increasing friction between the guide and the slider. This reduces the smoothness of guide movement, increases power consumption, and may even generate abnormal noises.

Thermal Conductivity: Elevated temperatures diminish the guide's thermal conductivity, impairing its heat dissipation capacity and further exacerbating temperature rise.

Wear Resistance: In high-temperature environments, the guide's wear resistance diminishes, accelerating wear on both guide and slider and shortening service life.

Material Properties: When temperatures exceed 100°C, the rated load capacity and service life of linear guides decline significantly. Under such conditions, both dynamic and static rated loads require adjustment based on temperature coefficients.

Thermal Deformation: Elevated temperatures induce thermal deformation in the guide rails, compromising their precision and rigidity. This deformation may also alter the contact stiffness between the guide rail and slider, further degrading overall performance.

Lubricant evaporation: Excessively high temperatures accelerate lubricant evaporation, leading to insufficient lubrication and consequently increased wear on the guide rails.

Component damage: Certain components, such as plastic seals, exhibit reduced resistance to high temperatures. Elevated temperatures may cause damage to these components, adversely affecting the overall performance of the guide rails.

In summary, the performance of linear guides is significantly affected by temperature. To ensure their stable operation, measures for heat dissipation and temperature control should be implemented, enabling the linear guides to maintain optimal operational conditions over the long term.
